Name: SWB805 Weigh Module 4.4T/10K C1 – 316 Stainless Steel High-Accuracy Load Cell
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Весовой модуль SWB805 316 4.4T/10K C1
Availability: InStock

Главная страница Продукция

SWB805 Weigh Module 4.4T/10K C1 – 316 Stainless Steel High-Accuracy Load Cell

Подробная информация о продукте:

Место происхождения:	Китай
Фирменное наименование:	Mettler Toledo
Номер модели:	Весовой модуль SWB805 316 4.4T/10K C1

Оплата и доставка Условия:

Количество мин заказа:	1 Комплект
Цена:	Подлежит обсуждению
Упаковывая детали:	Коробка с картофелем
Время доставки:	10-30 дней
Поставка способности:	2000 комплектов в месяц

контакт

Подробное описание продукта

Продукт:	Тензодатчик Mettler Toledo	Максимальная грузоподъемность:	10,000 фунтов (4,400 кг)
Материал:	316 из нержавеющей стали	метрология:	NTEP III 1.6 M OIML C1
Нагрузочная камера:	SLB815	Точность:	Низкий
Рейтинг защиты:	IP68/69k	Окружающая среда / Материал:	Частое промывание / Гигиеническое
Одобрение по опасности:	ATEX, FM, cFM	Критичность:	стандартный
Кабель:	5 m
Выделить:	316 stainless steel weigh module , high-accuracy 10K load cell , Mettler Toledo 4.4T load cell

SWB805 Weigh Module 4.4T/10K C1 – 316 Stainless Steel High-Accuracy Load Cell

Certified Hygienic Solution

Our weigh module is designed according to hygienic principles and certified by NSF, reducing contamination risk to a minimum.

Reduced Cleaning Time

Increased efficiency thanks to highly-polished, self-draining surfaces that clean and dry quickly. Visual inspection is easy due to the open design.

Easy to integrate

Our weigh modules are shipped in a locked position and can be integrated without interfering with the sealing, thus no risk of contamination.

Product Description

A compression weigh module is designed so that its top plate and base plate will be squeezed toward each other when weight is applied. It can be attached directly to the ground, piers or structural beams. Compression weigh modules are typically used in multiples under large platform scales such as truck and railroad track scales, and in tank, hopper and silo weighing. Capacities for compression load cells, which are within compression weigh modules, range from 3 kg to 300 tons.

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	10,000 lb (4,400 kg)
Material	316 Stainless steel
Metrology	NTEP III 1.6 M OIML C1
Load Cell	SLB815
Accuracy	Low
Protection Rating	IP68/69k
Environment / Material	Frequent wash-down / Hygienic
Hazardous Approval	ATEX, FM, cFM
Criticality	Standard
Cable	5 m
