Name: 5kg MT1022 Load Cell with 1m Cable – Ideal for Weighing Systems
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Датчик нагрузки MT1022-5kg 1м
Availability: InStock

Главная страница Продукция

5kg MT1022 Load Cell with 1m Cable – Ideal for Weighing Systems

Подробная информация о продукте:

Место происхождения:	КИТАЙ
Фирменное наименование:	Mettler Toledo
Номер модели:	Датчик нагрузки MT1022-5kg 1м

Оплата и доставка Условия:

Количество мин заказа:	1 комплект
Цена:	Подлежит обсуждению
Упаковывая детали:	Коробка с картофелем
Время доставки:	10-30 дней
Поставка способности:	2000 комплектов в месяц

контакт

Подробное описание продукта

Product:	Тензодатчик Mettler Toledo	Максимальная грузоподъемность:	5 кг
Материал:	Алюминий, пассивированный	Метрология:	NTEP III 5,000d OIML C3
Точность:	стандартный	Рейтинг защиты:	IP67
Размер платформы (LxW):	350 mm x 350 mm	Подключение:	Аналогичный
Кабель:	ПВХ
Выделить:	5kg MT1022 load cell , load cell with 1m cable , Mettler Toledo weighing system

5kg MT1022 Load Cell with 1m Cable – Ideal for Weighing Systems

Product Overview

A high-performance compression weigh module designed for precise measurement in industrial weighing applications. The MT1022 load cell features a top plate and base plate that compress under weight, allowing direct attachment to ground, piers, or structural beams. Ideal for platform scales, tank weighing, and hopper/silo applications with capacities ranging from 3 kg to 300 tons.

Key Features

Accuracy

High-performance single point load cell with off-center compensation for platform moments. Includes OIML metrology approvals as standard.

Reliable Strain Gage Technology

Manufactured with premium aluminum materials and advanced strain gage technology for exceptional long-term durability.

Hazardous Area Usage

Includes ATEX Zone 1/21/2/22 approvals as standard - no need for special options or variations.

Technical Specifications

Product	Mettler Toledo Load Cell
Maximum Capacity	11 lb (5 kg)
Material	Aluminum, passivated
Material No	71201826
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Platform Size (LxW)	350 mm x 350 mm
Connectivity	Analog
Cable	PVC
