Name: MT1041 75kg Load Cell – Robust Weight Sensor with 6 Meter Wire
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Датчик нагрузки MT1041-75kg 6м
Availability: InStock

Главная страница Продукция

MT1041 75kg Load Cell – Robust Weight Sensor with 6 Meter Wire

Подробная информация о продукте:

Место происхождения:	Китай
Фирменное наименование:	Mettler Toledo
Номер модели:	Датчик нагрузки MT1041-75kg 6м

Оплата и доставка Условия:

Количество мин заказа:	1 комплект
Цена:	Подлежит обсуждению
Упаковывая детали:	Коробка с картофелем
Время доставки:	10-30 дней
Поставка способности:	2000 комплектов в месяц

контакт

Подробное описание продукта

Продукт:	Тензодатчик Mettler Toledo	Максимальная грузоподъемность:	75 кг
Материал:	Алюминий, пассивированный	Метрология:	NTEP III 5000d OIML C3
Точность:	стандартный	Рейтинг защиты:	IP67
Размер платформы (LxW):	400 мм х 400 мм	Подключение:	Аналогичный
Кабель:	20 футов (6 м)
Выделить:	MT1041 75kg load cell , robust weight sensor with wire , Mettler Toledo load cell sensor

MT1041 75kg Load Cell – Robust Weight Sensor with 6 Meter Wire

A compression weigh module designed so that its top plate and base plate will be squeezed toward each other when weight is applied. It can be attached directly to the ground, piers or structural beams. Compression weigh modules are typically used in multiples under large platform scales such as truck and railroad track scales and in tank, hopper and silo weighing.

Product Attributes

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	196 lb (75 kg)
Material	Aluminum, passivated
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Platform Size (LxW)	400 mm x 400 mm
Connectivity	Analog
Cable	20 ft (6 m)

Key Features

For Mid Size Platforms

The MT1041 is a high performance single point load cell. The load cell is off-center compensated, enabling it to cope with platform moments. Metrology approvals include OIML as standard.

Reliable Strain Gage Technology

Usage of premium aluminum materials and strain gage technology guarantees long-term durability.

Hazardous Area Usage

ATEX Zone 1/21/2/22 approvals as standard. No need to ask for options or stock variations - one fits all applications.

Technical Specifications

Material: Aluminum, passivated

Material No: 72208504

Maximum Capacity: 196 lb (75 kg)

Protection Rating: IP67

Connectivity: Analog

Cable: PVC, 20 ft (6 m)

Platform Size (LxW): 400 mm x 400 mm
