Inspection Procedures for Industrial Weighing Systems

Подробная информация о продукте:

Место происхождения:	КНР
Номер модели:	Процедуры проверки для систем промышленного взвешивания

Оплата и доставка Условия:

Количество мин заказа:	1 набор
Цена:	Подлежит обсуждению
Упаковывая детали:	Кэрон коробка
Время доставки:	10-30 дней
Поставка способности:	2000 набор в месяц

контакт

Подробное описание продукта

Product:	Inspection Procedures for Industrial Weighing Systems	Weighing Range:	Min: 0.1 kg – Max: 50,000 kg (varies by model)
Tolerance (Error Limit):	±0.1% of reading (for Class III) or ±1 division (whichever is stricter)	Frequency:	Every 6 months (or after 500 hours of operation)
Calibration Weights:	Class F1/M1 (OIML R111) with valid certification	Temperature Range:	-10°C to +40°C (operational), -20°C to +60°C (storage)
Humidity Tolerance:	10% to 90% RH (non-condensing)	Load Cell Type:	Strain gauge (standard), Capacitive (high precision)
Overload Protection:	150% of max capacity (safety limit)	Power Supply:	110–240V AC, 50/60Hz or 24V DC (±5%)
EMC/EMI Resistance:	Complies with EN 61326-1 (industrial EMC standards)	Repeatability:	±0.05% of applied load (test with 10 repeated measurements)
Linearity Error:	±0.2% of full scale	Material Safety:	Stainless steel (Grade 316) for corrosive environments
Legal-for-Trade:	NTEP, MID (EU), OIML certification (if used in commerce)	Calibration Certificate:	Must include date, technician, uncertainty, traceability
User Manual:	Must cover installation, operation, maintenance, troubleshooting
Выделить:	industrial weighing system inspection , load cell inspection procedures , Mettler Toledo weighing system maintenance

Inspection Procedures for Industrial Weighing Systems

Comprehensive inspection procedures for industrial weighing systems to ensure accuracy, safety, and compliance with industry standards.

Technical Specifications

Attribute	Value
Weighing Range	Min: 0.1 kg – Max: 50,000 kg (varies by model)
Tolerance (Error Limit)	±0.1% of reading (for Class III) or ±1 division (whichever is stricter)
Frequency	Every 6 months (or after 500 hours of operation)
Calibration Weights	Class F1/M1 (OIML R111) with valid certification
Temperature Range	-10°C to +40°C (operational), -20°C to +60°C (storage)
Humidity Tolerance	10% to 90% RH (non-condensing)
Load Cell Type	Strain gauge (standard), Capacitive (high precision)
Overload Protection	150% of max capacity (safety limit)
Power Supply	110–240V AC, 50/60Hz or 24V DC (±5%)
EMC/EMI Resistance	Complies with EN 61326-1 (industrial EMC standards)

Inspection Process Overview

Industrial weighing system inspections involve evaluating mechanical integrity, electronic performance, and overall functionality to maintain measurement reliability and compliance.

Pre-Inspection Checks

Visual Inspection: Examine for damage, wear, or corrosion on platform and support structure
Cable and Connection Check: Verify all connections are secure and undamaged
Foundation and Environment: Assess for stability and environmental factors affecting performance

Calibration and Verification

Zero Balance Check: Verify stable zero reading with no load
Span Calibration: Test accuracy across weighing range using certified test weights
Repeatability Test: Confirm consistent readings with repeated measurements

Functional and Operational Tests
