Name: 100kg Load Cell MT1260 with 2m Cable – Industrial Grade Weighing Sensor
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Нагрузочная ячейка MT1260-100kg 2m
Availability: InStock

Главная страница Продукция

100kg Load Cell MT1260 with 2m Cable – Industrial Grade Weighing Sensor

Подробная информация о продукте:

Место происхождения:	КИТАЙ
Фирменное наименование:	Mettler Toledo
Номер модели:	Нагрузочная ячейка MT1260-100kg 2m

Оплата и доставка Условия:

Количество мин заказа:	1 комплект
Цена:	Подлежит обсуждению
Упаковывая детали:	Коробка с картофелем
Время доставки:	10-30 дней
Поставка способности:	2000 комплектов в месяц

контакт

Подробное описание продукта

Product:	Тензодатчик Mettler Toledo	Максимальная грузоподъемность:	220 фунтов (100 кг)
Материал:	Алюминий, пассивированный	Метрология:	NTEP III 5,000d OIML C3
Точность:	Стандарт	Рейтинг защиты:	IP67
Размер платформы (LxW):	400 мм х 400 мм	Связь:	Аналогичный
Кабель:	ПВХ
Выделить:	100kg load cell with 2m cable , industrial grade weighing sensor , Mettler Toledo load cell with warranty

100kg Load Cell MT1260 with 2m Cable – Industrial Grade Weighing Sensor

Key Features

High-performance single point load cell with off-center compensation
Industrial-grade aluminum construction with passivated finish
IP67 protection rating for durable operation in harsh environments
Includes ATEX Zone 1/21/2/22 approvals for hazardous area usage
Metrology approvals: NTEP III 5,000d and OIML C3

Product Description

The MT1260 compression weigh module is designed for industrial weighing applications where its top plate and base plate are compressed when weight is applied. This robust load cell can be directly attached to the ground, piers, or structural beams, making it ideal for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing systems.

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	220 lb (100 kg)
Material	Aluminum, passivated
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Platform Size (LxW)	400 mm x 400 mm
Connectivity	Analog
Cable	PVC

Reliable Performance

This load cell utilizes advanced strain gauge technology and premium aluminum materials to ensure long-term durability and consistent performance. The off-center compensation design effectively handles platform moments, while the standardized metrology approvals guarantee measurement accuracy.
